Technical Specifications
| Brand | Bianco Pumpz |
| Product Type | Circulator Pump |
| Suitable For | Solar Hot Water |
| Flow Range Category | b. 100 - 199 L/min |
| Flow Rate (L/min) | 130 L/min |
| Head Range Category | a. 0 - 39 m |
| Max Head (m) | 8 m |
| Port Size Outlet | 2" BSPM outlet |
| Warranty (months) | 24 Months |
| Volts | 240 V |
Description
This is a pump used for domestic hot water circulating. The Stainless steel housing makes it suitable for underfloor heating. It is maintenance free and is low in noise. Comes complete with 2" F x 1-1/4" F unions.
Features
The pump is characterised by:
- Circulation body materials suitable for potable water
- 3 speed operation
- Flows to 130 l/min
- Heads to 8m
Liquid temperature: 2OC - 110OC
Materials: Pump body: Stainless Steel 304 SS
Impeller: Corrosion resistant composite PPO
Back Plate and Rotor Can: Stainless Steel 304 SS
Unions: 2" F x 1-1/4"F Unions Stainless Steel 304 SS
Installation: Maximum ambient temperature: 40OC
Maximum Operating Pressure: 10 bar
Port spacing: 180mm
Port size: 2” BSPM (1-1/4” BSPF if used with supplied unions)
Electrical Data: 230V
